This Picatinny optics rail replaces the wood upper on your Springfield Armory M1 Carbine with a full-metal aluminum rail. It's easy to install and allows you to mount your choice of optics.
Springfield Armory M1 Carbine Optic Mount
- Picatinny rail for mounting optics
- Full-metal construction
- Fits .177 BB and 6mm airsoft Springfield Armory M1 Carbine
- Easy to install
- Manufacturer Springfield Armory
- Condition New
- Accessories Type Scope Mounts
- Warranty 1-year limited warranty
- Weight 0.30
Question?
Login to ask someone who bought this product.How do you put the Rail on the M1 Carbine 177? How do you take off the cover.?
asked Jon from USAI highly recommend the rail. It's better looking, tightens up the fit and much less rattling of the fore guard. 1.) remove the hand guard (see YouTube video below) https://www.youtube.com/watch?v=FZBBzLrMyNc&list=PL9RriW3G9WX7ffaGRTdPMjkGozxwsxJ5L&index=1 2.) there are two "barrel saddles" holding the barrel to the rifle, remove the two screws from the muzzle end saddle, save the screws. 3.) insert the rail so the v-notch faces rear where the plastic fore guard sat. 4.) using the screws from the front saddle, attach the rail to the rifle using the same holes the saddle was attached with. The forward saddle is no longer needed. Resecure the fore guard strap securely. All set.
James from USAThere are screws to remove, slide the strap (holding the hand guard on) and the hand guard itself can slide off, reverse to install. See youtube video here: https://www.youtube.com/watch?v=FZBBzLrMyNc&list=PL9RriW3G9WX7ffaGRTdPMjkGozxwsxJ5L&index=1
James from USAWill this fit the Springfield Armory M1A 22 Cal Air Venturi Underlever Air Rifle?
asked John from USANo, it is only for the AV M1 carbine.
Randall from USA
It's easy to install. Remove front strap, remove the fore guard, remove front barrel saddle, save screws. Put the rail where the fore guard was paying attention to the v-notch (plastic/wood fore guard has same notch). Once placed, use the two screws removed from the front saddle to secure the rail to the rifle in the same holes the screws were removed from. There are two holes in the rail for this purpose. Reattach the fore guard strap as you removed it.
Pros
Tightens up the loose fit of the fore guard, greatly reduces the rattling sound. Looks 1000% better. Much more milspec appearance.
Cons
Post a video showing how easy to install.
